XR550 Control Panel
This fully scalable and flexible panel series meets your most demanding commercial or large residential applications.
The flagship DMP XR550 integrates intrusion and commercial fire with powerful access control capabilities. Featuring more total zones, wireless zones, areas, keypads and access control doors than any other panel in its class, plus AES encrypted communication options.
The XR550 is a workhorse that can handle virtually any application from extremely large residential to high-security industrial to multi-site nationwide footprint installations.
- 96 doors of access control
- 10,000 user codes with 99 profiles
- Encrypted 10/100 network or Wi-Fi, LTE cellular or dialer
- Select Area, All/Perimeter or Home/Sleep/Away operation
- Remote flash update and programming
- Adaptive Technology™
- Multi-lingual menus per user
- UL bank, safe and vault
- Card Plus Pin and Dual Authority
- Lockdown operation from keypad or app
- 99 assignable schedules for areas, doors and profiles
- Small to large business
- Banks
- Commercial
- Enterprise level solution
- Large scale customizable management
- XR550DEA-G Dialer & Encrypted Network Panel in Large Attack Enclosure
- XR550DEL-G Dialer & Encrypted Network Panel in Large Gray Enclosure
- XR550DEL-GCAN Dialer & Encrypted Network Panel in Large Gray Enclosure - Canada
- XR550DEL-GZ Dialer & Encrypted Network Panel in Large Gray Enclosure, No transformer
- XR550DEPCB Dialer & Encrypted Network Panel, Board Only
- XR550DEPCBZ Dialer & Encrypted Network Panel, Board Only, No transformer
- XR550DNL-G Dialer & Network Panel in Large Gray Enclosure
- XR550DNL-GCAN Dialer & Network Panel in Large Gray Enclosure
- XR550DNL-GZ Dialer & Network Panel in Large Gray Enclosure, No transformer
- XR550DNL-R Dialer & Network Panel in Large Red Enclosure
- XR550DNPCB Dialer & Network Panel, Board Only
- XR550DNPCBZ Dialer & Network Panel, Board Only, No transformer
- XR550DL-G Dialer Panel in Large Gray Enclosure
- XR550EA-G Encrypted Network Panel in Large Attack Enclosure
- XR550EL-G Encrypted Network Panel in Large Gray Enclosure
- XR550EPCB Encrypted Network Panel, Board Only
- XR550NL-G Network Panel in Large Gray Enclosure
- XR550NL-GCAN Network Panel in Large Gray Enclosure - Canada
- XR550NL-GZ Network Panel in Large Gray Enclosure, No transformer
- XR550NPCB Network Panel, Board Only
- XR550NPCBZ Network Panel, Board Only, No transformer
FCC Part 15
FCC Part 68 Registration ID CCKAL00BXR550
California State Fire Marshall (CSFM)
New York City Fire Department (FDNY)
Los Angeles Fire Department (LAFD)
NIST AES Algorithm Certification
- #2350 128-bit
- #2595 256-bit
Underwriters Laboratories Listings
- ANSI/UL 294 - Access Control System Units
- Level I - Destructive Attack and Line Security
- Level IV - Endurance and Standby Power
- ANSI/UL 365 - Police Station Connected Burglar Alarm Units and Systems
- ANSI/UL 464 - Audible Signal Appliances
- ANSI/UL 609 - Local Burglar Alarm Units
- ANSI/UL 864 - Control Units for Fire Protective Signaling Systems
- ANSI/UL 985 - Household Fire Warning System Units
- ANSI/UL 1023 - Household Burglar Alarm System Units
- ANSI/UL 1076 - Proprietary Burglar Alarm Systems and Units
- ANSI/UL 1610 - Central Station Burglar Alarm Units
- ANSI/UL 1635 - Digital Alarm Communicator System Units
- ANSI/UL 2017 - General Purpose Signaling Devices and Systems
Underwriters Laboratory of Canada Listings
- ULC-S304 - Standard for Central and Monitoring Station Burglar Alarm Units
- ULC-S545 - Standard for Residential Fire Warning System Control Units
- ULC-S559-13 - Equipment for Fire Signal Receiving Centers and Systems
- ULC-C1023 - Household Burglar Alarm System Units
- ULC/ORD-C1076 - Standard for Proprietary Burglar Alarm Units and Systems
Compatible with Devices Listed For
- ANSI/UL 268 - Smoke Detectors for Fire Alarm Signaling Systems
- ANSI/UL 364 - Waterflow Indicators for Fire Protective Signaling Systems
- ANSI/UL 636 - Holdup Alarm Units and Systems
- UL Bank, Safe, and Vault
- UL Standard Line Security
- UL Encrypted Line Security
Export Control
The XR550 with encryption uses AES encryption and any export beyond the United States must be in accordance with Export Administration Regulations.
See XR Series Compliance Note (LT-2509) and XR Series Compliance Guide (LT-1330).
Product Resources
Specs & Guides
Version 254 | September 17, 2025
Panel Serial Number in Serial 3 Messages
This update allows you to enable Serial 3 messages to include the panel serial number. If enabled, the panel family and corresponding serial number appear at the end of each Serial 3 message, allowing the monitoring center to identify the correct system if two panels unintentionally use the same account numbers.
This update requires one of the following:
- SCS-VR Virtual Receiver
- SCS-1R Network Enabled Receiver with the SCS-150 Main Processor Card at firmware Version 108 (9/23/25).
To enable Serial 3 messages to include the XR Series panel serial number, complete the following steps:
- At the keypad, enter 6653 (PROG) and select CMD to enter the programming menu.
- At SYSTEM REPORTS, go to SYSTEM INFORMATION.
- Select YES to enable Serial 3 messages to include the panel serial number. The default option is set to NO.
- Go to STOP to save programming.
To program Serial 3 messages to include the panel serial number on Dealer Admin, refer to TU-1484.
Holdup Zone Type
A new zone type called Holdup has been added to Zone Information. Holdup zones operate as silent panics and do not trigger bell actions, or audible or visual alerts on the keypad.
To program a zone type as Holdup at the keypad, complete the following steps:
- At the keypad, enter 6653 (PROG) and press CMD to enter the Programmer menu.
- At ZONE INFORMATION, go to ZONE TYPE.
- Press CMD to view additional zone types until you see HU (Holdup) as an option.
- Select HU (Holdup) as the zone type, then press CMD.
- Configure additional Zone Information options as needed.
- Go to STOP to save programming.
To program a zone type as Holdup in Dealer Admin, refer to TU-1484.
Z-Wave Improvements
Previously the 738Z+ Z-Wave Plus Interface Module would remain in an action for longer than desired. This update allows the 738Z+ to return to its default state for quicker adding, editing, and deleting of Z-Wave devices and actions.
